High Speed Thread Rolling Machine
High Speed Thread Rolling Machine
High-speed thread rolling machine with cover, models like CTR-2, CTR-4, CTR-5, CTR-6, CTR-8, and CTR-9, featuring varying capacities and dimensions.
| MODLE | MAX THREAD DIAMETER | MAX THREAD LENGTH(mm) | MOVING DIES STATIONARY LENGTH(mm) | MOTOR(HP) | CAPACITY (PCS,MIN) | PACKING VOLUME (CM) | Weight(kg) GW | |
| CTR-2 | 1-3 | 25 | 51*64*19 | 1-1/4-1/8 | 180-500 | 120*85*135 | 500 | 600 |
| CTR-4 | 2-4 | 32 | 65*75*19 75*90*25 | 2-1/4-1/8 | 180-450 | 150*110*145 | 850 | 950 |
| CTR-5 | 2-5 | 32 | 75*90*25 | 3-1/4-1/8 | 180-430 | 165*120*150 | 900 | 1050 |
| CTR-6 | 3-6 | 50 | 90*105*25 | 5-1/4-1/8 | 200-300 | 170*150*160 | 1250 | 1400 |
| CTR-8 | 3-8 | 76 | 108*127 | 5-1/2-1/8 | 120-230 | 190*200*175 | 1800 | 2030 |
| CTR-9 | 4-9 | 76 | 127*140*25 | 15-1/2-2 | 80-250 | 165*240*180 | 4000 | 4400 |
